Dwyer DPMW-404 LCD Digital Panel Meter
Normally In Stock
Code: 570918
Dwyer DPMW-404 - LCD digital panel meter, loop powered 4 to 20 mA, red segments.
Condition: New
Usually ships Same Day or Next Day$184.87
Sale Price
$154.06
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer DPMW-404 is an LCD Digital Panel Meter with a temperature range of 32 to 122°F (0 to 50°C) and an accuracy of ±(0.1% FS + 2 count). It has adjustable zero and span adjustments (±1999 Counts) and a snap-in bezel mount. The meter features a 3-1/2 digit, 7 segment display and screw terminals for easy connection. It is available in two voltage options: DPMP-4XX(P) powered by the control loop and DPMP-5XX(P) with 12 VDC or 24 VDC power. Multiple engineering units are available, and the conversion rate is 3 per second. The meter is polarity automatic with a "-" displayed. It also has a 24 VDC backlight power supply.
Specifications
Component
Digital Panel Meter
(Instrument-Sensor) Measurement Accuracy
0.10%
Sub Component
LCD
(Instrument-Sensor) Temperature Range
32 - 122°F/0 - 50°C
Manufacturer
Dwyer Instruments
Features
Panel mount for quick installation
3-1/2 or 4-1/2 digit with 0.45˝ or 1˝ segments
Colored segments available in black, red, amber, green, or blue
Jumper selectable engineering units and decimal point positions
