Phoenix Contact 2909576 Power supply unit QUINT4-PS/1AC/24DC/2.5/PT
Normally In Stock
Code: 36877
QUINT4-PS/1AC/24DC/2.5/PT Phoenix Contact QUINT4-PS/1AC/24DC/2.5/PT. 24 volt 2.5 Amp Premium Power Supply(Class 1 Div 2) with input voltage 85-240 Vac or 90-350 Vdc. Temperature range of -13 F to 158 F. Din rail mount Screw Connection.
Condition: New
Usually ships Same Day or Next Day$119.76
Sale Price
$99.80
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2909576 The QUINT POWER is a primary-switched power supply unit that features a push-in connection and can be mounted on a DIN rail. It has an input capacity of 1-phase and provides a 24V DC output with a maximum current rating of 2.5A.
Specifications
Power Supply Type
Switching
Power Supply Mounting
Din Rail Mount
Power Supply Number of Outputs
Single Output
Power Supply Voltage Output
24 VDC
Power Supply Watts
60 Watt
Power Supply Housing
Enclosed
Power Supply Amperage Output
2.5 Amp
Component
Power Supply
Manufacturer
Phoenix Contact
Line
QUINT
Power Supply Amperage Output Range
0-5 Amp
Power Supply Voltage Input Range
85 VAC - 264 VAC
Power Supply Voltage Input Range
90 VDC - 350 VDC
Features
Space savings in the control cabinet, thanks to a narrow, slim-line design
Preventive function monitoring indicates critical operating states before errors occur
High efficiency and long service life, with low power dissipation and low heating
Starting of heavy loads with dynamic boost
Free selection between Push-in and screw connection
Downloads
Phoenix 2909576 CAD data International.dxfPhoenix 2909576 CAD data International.pdfPhoenix 2909576 CAD data International.stpPhoenix 2909576 Data Sheet English.pdfPhoenix 2909576 Manufacturers declaration English.pdfPhoenix 2909576 Manufacturers declaration International-2.pdfPhoenix 2909576 Manufacturers declaration International.pdfPhoenix 2909576 Tender Text English.zipPhoenix 2909576 Various English.pdfPhoenix 2909576 Various English.wmv
