Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Phoenix Contact 1115657 Electronic circuit breaker CAPAROC E4 12-24DC/1-4A
Normally In Stock
Code: 240881
CAPAROC E4 12-24DC/1-4A Phoenix Contact 1115657 Electronic circuit breaker - CAPAROC E4 12-24DC/1-4A
Condition: New
Usually ships within 7-14 days. Call for ship time$128.70
Sale Price
$107.25
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1115657 A four-channel electronic circuit breaker module is designed to safeguard DC loads of 12 and 24V, shielding them against excessive currents and short circuits. This device allows for adjusting the nominal current setting between 1A and 4A using an LED button, making it convenient to customize protection levels as needed. The module can be easily mounted on DIN rails utilizing CAPAROC's current rails, ensuring secure and space-efficient installation.
Specifications
Breaker Mount Type
Din Rail
Breaker Amperage Rating
1 Amp
Breaker Amperage Rating
4 Amp
Breaker Voltage Rating
24 VDC
Manufacturer
Phoenix Contact
Breaker Voltage Rating
12 VDC
Component
Electronic Circuit Breaker
Features
The benchmark that you can tailor with the individual combination of multi-channel protective modules
Easy operation for everyone through tool-free assembly, uninterrupted installation, and transparent operating state
Exceptionally easy design-in with four separately fused channels with the narrowest of space requirements of just 3 mm per channel
Code: 240881
Phoenix Contact 1115657 Electronic circuit breaker CAPAROC E4 12-24DC/1-4A
$128.70
Sale Price
$107.25
