LCD Operator with Real Time Clock: 5-line, 16-character alpha-numeric display with time and date stamping for events, along with timer controls for starting, stopping, and speed changes without the need for external controls.

Application Macros: Choose from pre-configured fan and pump setup macros to match the application for quick and easy set up.

Selectable and Custom Engineering Units: Allows for easy configuration of keypad display to match process and feedback devices such as PSI, GPM, Feet.

Underload Detection: Monitors load and will shut system down in the event of a fan belt or pump shaft breakdown.

Parameter Storage and Removable Terminal Board: Allows for easy replacement of control card without removing control wires, and stores all drive settings without the need for a copy device.

PI Process Control: Maintains a set point for closed loop control of fans and pumps for pressure, flow, or temperature regulation, and eliminates the need for a closed loop output signal from a process controller. Independent PI to control an external device in the system.

Power Quality: Built-in DC reactors (30 HP and larger) provide input harmonics benefit, and protection from input disturbances. Integrated 12 Pulse version (480V, 40 HP and larger) provides a cost-effective solution for low harmonics.
