Code: 147344
Phoenix Contact 1751215 PCB terminal block SPTA 1,5/ 7-5,08
Normally In Stock
Phoenix Contact 1751215 SPTA 1,5/ 7-5,08 ,Copper Alloy,PA,I PCB terminal block
Condition: New
CALL FOR LEAD TIME$5.05
Sale Price
$4.21
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 1751215 A printed circuit board terminal has a nominal current rating of 17.5 A and is rated for up to 320 V with an internal cross-section of 1.5 mm², featuring seven potential connections arranged in a single row of seven positions. The product range is SPTA 1,5/, with a pitch of 5.08 mm and utilizing push-in spring connections for mounting via wave soldering.
Specifications
Terminal Block Voltage Rating
250 Volt
Terminal Block Voltage Rating
630 Volt
Terminal Block Number of Connections
7
Terminal Block Voltage Rating
320 Volt
Component
Terminal Block
Manufacturer
Phoenix Contact
Terminal Block Amperage
9 Amp
Sub Component
Printed Circuit Board Terminal
Terminal Block Voltage Rating
4 Kv
Model Type
SPTA
Features
Time saving push-in connection, tools not required
Defined contact force ensures that contact remains stable over the long term
Intuitive operation due to color-coded actuating push button
Angled connection enables multi-row arrangement on the PCB
Quick and convenient testing using integrated test option
Two solder pins reduce the mechanical strain on the soldering spots
