Precision Accuracy

Two 4-20mA outputs (configurable)

Durable

Fast Response Time

Accuracy± 0.5 °C (± 0.9 °F)

Additional Features 1NIST Traceable

Air Velocity, Max900 m/mn

Data InterfaceRS232

Dew Point Temperature, Max60 °C

Dew Point Temperature, Min-20 °C

Dew Point Temperature NoteDew Point -20°C (@ 25°C) to 60°C (non-condensing) Dew Point -40°C (@ 0°C) Temperature probe: (optional) - 40°C to 120°C

Electrical Output4 to 20 mA

Materials, WettedAnodized Aluminum, Nickel

Operating Temperature, Max120 °C

Operating Temperature, Min-40 °C

Output Detail(2) 4 to 20mA output at 24Vdc (configurable). Default settings: - 20°C to 60°C (unless specified on purchase order. Analog Output scaled range Dew Point (4- 20mA) User Selectable: 2) 4-20mA -24 Vdc (configurable) Factory set-both outputs, -20C to 60C (unless specified on order)

Pressure LimitsUp to 29 psi

Pressure, Min0 psi

Repeatability± 0.05°C

Resolution0.0001

Supply Power TypeDC

Supply Voltage24 Vdc

Temperature Measurement, Max60 °C

Temperature Measurement, Min-40 °C

Weight5 lb
