Code: 779380
Omega FMA3805 CONTROLLR W/0 DISPLAY 200SCCM
Normally In Stock
Omega FMA3805 CONTROLLR W/0 DISPLAY 200SCCM
Condition: New
Usually ships Same Day or Next Day$2545.08
Sale Price
$2120.90
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Mass Flow Controller, Gas, 2 SCCM to 200 SCCM, 500 psi, 50 °C (122 °F), ± 1 %, 1/4 " Compression, 0 Vdc to 5 Vdc, 4 mA to 20 mA, Power Supply Included, 316 SS, FKM, FMA3800 Series, Each
Specifications
(Instrument-Sensor) Supply Voltage
24 VDC
(Instrument-Sensor) Medium
Air
(Instrument-Sensor) Medium
Nitrogen
Manufacturer
Omega Engineering
(Instrument-Sensor) Medium
Gases
(Instrument-Sensor) Medium
Oxygen
Component
Mass Flow Meter
(Instrument-Sensor) Span
0 To 500 Psi
Features
Economical
Compact
Power Supply Included
Accuracy± 1 %
Accuracy Detail± 1% of full scale including linearity
Additional Features 1Power Supply Included
CalibrationNIST 5-Point Certificate
Control ValveSolenoid Valve NC
Electrical ConnectionSub-D Male Miniature Connector
Electrical Output4 to 20 mA, 0 to 5 Vdc
Height6 in
Leak Rate Under Vacuumless than 10^⁻⁶ cc He/s
Length3.29 in
Materials, Wetted17-4 Stainless Steel, 316 Stainless Steel, FKM
Media CompatibilityAir, Gases, Nitrogen, Oxygen
Operating Pressure, Max500 psi
Operating Pressure, Min0 psi
Operating Temperature, Max50 °C
Operating Temperature, Min0 °C
Output DetailLinear 0 to 5 Vdc,1000 Ω min load, 4 to 20 mA,500 Ω loop resistance
Output SignalCurrent, Voltage
Pressure Coefficient0.01% FS/psi
Process Connection Size1/4 in
Process Connection TypeCompression Fitting
Repeatability± 0.15%
Required Pressure, Min1 inH₂O
Response Time5 sec
Temperature Coefficient0.05% FS/°C
Turndown Ratio100:1
Volumetric Flow Rate, Min0.1 SCCM
Weight1.25 lb
Width1 in
