Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 722654
Phoenix Contact 1416285 Device connector front mounting SACC-E-MS-5CON-M16/2,0 SCO
Normally In Stock
Phoenix Contact SACC-E-MS-5CON-M16/2,0 SCO - Device connector front mounting, 5 Positions, 60 VAC, 4 Amp, CuZn - 1416285
Condition: New
Usually ships Same Day or Next Day$21.60
Sale Price
$18.00
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1416285 A device connector with a front-mounted design and a universal fit is available in 5-position Pin configuration, using an M12-SPEEDCON coding system with the letter "A" on the free cable end. The connector is attached to a mounting plate via an M16 x 1.5 screw, allowing for individual wire connection, and comes with a 2m long cable featuring TPE litz wires that are potted in insulation.
Specifications
Connector Amperage
4 Amp
Connector Material
Cuzn
Component
Circular Connector
Manufacturer
Phoenix Contact
Number of Positions
5
Features
Preassembled with litz wires for immediate use
Customer-specific assemblies and litz wire lengths available
Sealed on the litz wire side for optimum leak-tightness
All standard pin assignments and codings for signal, data, and power transmission with a uniform design-in design
For high transmission safety: shield connection to the housing with optional EMC nut
SPEEDCON fast locking system reduces cabling times
