Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 72121
Phoenix Contact 2800645 Lightning/surge arrester type 1/2 VAL-MS-T1/T2 335/12.5/4+0
Normally In Stock
VAL-MS-T1/T2 335/12.5/4+0 Phoenix 2800645 Arrester combination 240/415 VAC Screw connection,Fork-type cable lug Lightning/surge arrester type 1/2 Surge Protection
Condition: New
Usually ships within 7-14 days. Call for ship time.$876.49
Sale Price
$730.41
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2800645 A universal varistor-based plug-in lightning/surge arrester is designed specifically for 3-phase power supply networks that utilize a separate neutral and earth conductor. This type of system features five conductors: three phase lines (L1, L2, L3) and two additional lines for the neutral (N) and earth (PE), allowing for improved safety and reliability in high-voltage environments.
Specifications
Max Discharge Capacity
80 A
Direction of Action
(L+)-PE
Direction of Action
(L-)-PE
Direction of Action
(L+)-(L-)
Manufacturer
Phoenix Contact
Connection Method
Screw Connection
Surge Protector Type
Base Element
Surge Protector Line Voltage
240-415 Volt
Component
Surge Arrester
Features
Can be used in lightning protection level III and IV due to discharge capacity of 12.5 kA per position
Rapid installation with bridges, thanks to industry-standard overall width of 1 HP
Easy testing and insulation measurement, thanks to pluggable protection modules
Quality proven millions of times over in the widest range of applications
Vibration-resistant latching ensures the plug remains firmly in place
Downloads
Phoenix 2800645 CAD data International.dxfPhoenix 2800645 CAD data International.pdfPhoenix 2800645 CAD data International.stpPhoenix 2800645 Flyer English.pdfPhoenix 2800645 Manufacturers declaration International.pdfPhoenix 2800645 Package Slip International.pdfPhoenix 2800645 Software International.zipPhoenix 2800645 Surge Protection English.pdfPhoenix 2800645 Tender Text English.zip
