Phoenix Contact 2800190 Type 1/2 surge protection plug VAL-MS-T1/T2 335/12.5 ST
Normally In Stock
Code: 71991
VAL-MS-T1/T2 335/12.5 ST Phoenix 2800190 Replacement plug 240/415 VAC pluggable Type 1/2 surge protection plug Surge Protection
Condition: New
Usually ships within 7-14 days. Call for ship time.$178.67
Sale Price
$148.89
MUST BUY IN PACKS OF 10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2800190 L-N replacement plug for VAL-MS-T1/T2 335/12.5 plug-in lighting/surge arrester.
Specifications
Fault Warning
None
Arrester Class according to IEC
C1
Arrester Class according to IEC
C2
Arrester Class according to IEC
C3
Arrester Class according to IEC
D1
Arrester Class according to IEC
B2
Arrester Class according to IEC
A2
Arrester Class according to IEC
B1
Arrester Class according to IEC
B3
Arrester Class according to IEC
D2
Direction of Action
Line-Line
Direction of Action
Line-Earth Ground
Manufacturer
Phoenix Contact
Connection Method
Screw Connection
Surge Protector Type
Surge Protection For Information Technology
Maximum Continous Voltage
± 180 Volt
Nominal Discharge Current
5 Ka
Surge Protector Line Voltage
240-415 Volt
Component
Surge Protection Plug
Features
Can be used in lightning protection level III and IV due to discharge capacity of 12.5 kA per position
Rapid installation with bridges, thanks to industry-standard overall width of 1 HP
Easy testing and insulation measurement, thanks to pluggable protection modules
Quality proven millions of times over in the widest range of applications
Vibration-resistant latching ensures the plug remains firmly in place
Downloads
Phoenix 2800190 CAD data International.dxfPhoenix 2800190 CAD data International.pdfPhoenix 2800190 CAD data International.stpPhoenix 2800190 Flyer English.pdfPhoenix 2800190 Manufacturers declaration International.pdfPhoenix 2800190 Package Slip International.pdfPhoenix 2800190 Software International.zipPhoenix 2800190 Surge Protection English.pdfPhoenix 2800190 Tender Text English.zip
