Phoenix Contact 2801296 Supply and remote module PT-IQ-PTB-PT
Normally In Stock
Code: 71677
PT-IQ-PTB-PT Phoenix 2801296 Surge protection for measurement and control technology Push-in connection,DIN rail NS35 Supply and remote module Surge Protection
Condition: New
Usually ships within 7-14 days. Call for ship time.$282.29
Sale Price
$235.24
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2801296 This module manages power supply and enables multi-stage remote signaling for connected surge protection units, allowing for effective communication and coordination among the different components.
Specifications
Max Discharge Capacity
80 A
Fault Warning
Optical
Arrester Class according to IEC
PV I - II
Arrester Class according to IEC
PV T1 - T2
Impulse Discharge Current
5 Ka
Manufacturer
Phoenix Contact
Component
Accessories
Connection Method
Screw Connection
Surge Protector Type
PV Arrester
Nominal Discharge Current
15 Ka
Sub Component
Remote Module
Features
Supply of up to 28 protective devices due to high feed-in power
Integration of the status message into the system controller via group remote signaling
Install quickly and error-free with DIN rail connectors
Predictive monitoring with 3-stage LED display
Maximum protection for MCR applications with high discharge capacity
Downloads
Phoenix 2801296 CAD data International.dxfPhoenix 2801296 CAD data International.pdfPhoenix 2801296 CAD data International.stpPhoenix 2801296 Flyer English-2.pdfPhoenix 2801296 Flyer English.pdfPhoenix 2801296 Manufacturers declaration International.pdfPhoenix 2801296 Package Slip International.pdfPhoenix 2801296 Product Information English.pdfPhoenix 2801296 Software International.zipPhoenix 2801296 Surge Protection English.pdfPhoenix 2801296 Tender Text English.zip
