Ilsco ACON-2/0 Pigtail Adaptor - Aluminum, Stranded, 600 V, Silver
Normally In Stock
Code: 588288
Ilsco ACON-2/0 - Aluminum Compression Pigtail Adaptor offset, Conductor size 20, Tin Plated, cULus
Condition: New
CALL FOR LEAD TIME$60.48
Sale Price
$46.52
NO MOQ/PACK QUANTITY. QTY 1 = QTY 1
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Ilsco ACON-2/0 - Ilsco's Aluminum Compression Pigtail Adaptor is cULus approved with a NEMA Code of S-588-3. Featuring a tin-plated finish, it is rated for 600V voltage and has a temperature rating of 90°C. Designed for 20 AWG conductors, this connector is suitable for both copper and aluminum wires. Includes insulating cover. (50 words)
Specifications
Color
Silver
Manufacturer
Ilsco
Material
Aluminum
Maximum Operating Temperature (Fahrenheit)
194 °F
Maximum Operating Temperature (Celsius)
90 °C
Connector Finish
Tin
Voltage Rating
600 V
Component
Pigtail Adaptor
Features
Manufactured from high strength aluminum alloy
ACMN pin is center, ACON pin is off center
Chamfered barrel
cULus listed for 35KV, 90˚C
Clearly marked with wire size and die index for ILSCO tools, proper number & location of crimps
Prefilled with DE-OX®
Color coded end caps inserted in barrel
Supplied with insulating cover, cULus listed for 600 volts, 90˚C
