Code: 582484
Absolute Process Instruments K121-C Universal Converter
Normally In Stock
API K121-C - Universal isolator, loop powered, calibrated to order, Specify input type and range: ±150 mV, ±30 V, ±24 mA, RTD, T/C, Potentiometer, Resistance, Output: 4-20 mA loop powered
Condition: New
Ships in 10 to 15 Business Days$230.86
Sale Price
$192.38
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
API K121-C - Universal isolator, loop powered, calibrated to order, Specify input type and range: ±150 mV, ±30 V, ±24 mA, RTD, T/C, Potentiometer, Resistance, Output: 4-20 mA loop powered
Specifications
Manufacturer
Absolute Process Instruments
Component
DC To Frequency Transmitters
Conditioner Supply Voltage
115 VAC
Features
K121 supports all standard thermocouples, J, K, R, S, T, B, E, N, L (EN 60584 ) and Pt100, Pt500, Pt1000, Ni100, NI120, NI1000, Cu50, Cu100 thermoresistances with 2, 3 or 4 wires connection. The accuracy class is 0.1% and the measurement conversion to 16 bit. K121 is equipped with 2-way 1500 Vac galvanic isolation and is ATEX “II 3G Ex nA IIC T4 Gc X” compliant.
K121 also accepts voltage signals with ± 30 V and ± 150 mV and current (± 24 mA) scales.
The instrument also acquires potentiometer input with resistance between 500 Ω and 10 K Ω and resistances up to 1760 Ω. K121 features a reduced response time of only 140 ms for current and voltage input and less than 620 ms for other inputs.
