nVent Hoffman A8R84HM WEATHERFLO Enclosure with Fan, Type 3R
Normally In Stock
Code: 42527
nVent Hoffman A8R84HM Horizontal-Mount, Type 3R Outdoor-Indoor 8" x 8" x 4" (HxWxD) Steel Enclosure. Top Mount Painted Steel with Screw Lift-Off latch None. (DOES NOT INCLUDE BACK PANEL)
Condition: New
Usually ships Same Day or Next DayDOES NOT INCLUDE BACK PANEL
$93.97
Sale Price
$78.31
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
nVent Hoffman A8R84HM WEATHERFLO Enclosure with Fan, Type 3R WEATHERFLO Enclosure Type 3R outdoor or indoor use with lift off hinged door with quarter turn latch and forced-air ventilation system. Ideal for cooling high-heat producing equipment like drives or other equipment in outdoor applications. Adjustable thermostat 70-140 with active cooling fan and filter with easy accessable washable metal filter, and withtop front hood exhaust door. White powder coat finish for low solar absorbtion, integrated solar shield top and intake cover, welded mounting brackets, terminal power connection for fan, stay in place gasket, and grouding provisions. Studs for adding backplate for mounting equipment.
Specifications
Enclosure Composition
Galvanized Steel
Enclosure Depth
4"
Enclosure Environment Rating
Outdoor-Indoor
Enclosure Lock Type
Padlocking
Enclosure Interior Color
Gray
Enclosure Height
8"
Enclosure Width
8"
Line
WEATHERFLO
Enclosure Door Type
Solid
Enclosure Mount Type
Wall Mount
Enclosure Latch Type
Screw
Component
Commercial Enclosure
Enclosure Number of Doors
1 Door
Enclosure NEMA Rating
NEMA Type 3R
Enclosure Type
Screw-Cover Enclosure
Manufacturer
Hoffman
Features
Mounting holes on back for direct mounting through the back to strut or mounting surface, vertical structure for mounting not required
Screw locations on cover are embossed
Enclosure body flange is formed outward
Included mounting brackets provide a 1-inch clearance off surface for protection against pooling water
No gasketing
The screw cover is the drip shield providing 3/4-inch overhang on each side for outdoor protection
Enclosures are finished with paint over plated surfaces
