Schneider Electric HMISTU855W 5.7 inch HMI Screen 24 VDC 6.8 Watts, Full Color Touch Screen Interface UL 508 Ø 22 mm hole mount
Normally In Stock
Code: 41395
Schneider Electric HMISTU855W 5.7 inch HMI Screen with 6.8 Watts max power consumption at 24 VDC, a Full Color Touch Screen Interface with a display resolution of 320 x 240 pixels. This HMI Screen is UL 508 certified and is mounted with a Ø 22 mm hole mount. (REQUIRES Vijeo Desig
Condition: New
Usually ships Same Day or Next Day$1239.54
Sale Price
$1032.95
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Schneider Electric HMISTU855W 5.7 inch HMI Screen is designed to be a compact, cost effective solution for machine builders. This HMI screen has 6.8 Watts of max power consumption at 24 VDC, a Full Color Touch Screen Interface with a display resolution of 320 x 240 pixels. This HMI Screen is UL 508 certified and is mounted with a Ø 22 mm hole mount and includes 3 connection types: 1 USB 2.0 type mini B, 1 USB 2.0 type A and RJ45 RS232C/RS485. (REQUIRES Vijeo Designer configuration software TO CONFIGURE. SOLD SEPARATLY)
Specifications
HMI & PC Software
Vijeo Designer Configuration Software
HMI & PC Supply Voltage DC
24 VDC
HMI & PC Display Color
Full Color
HMI & PC UL Certification
UL 508
HMI & PC NEMA Rating
NEMA 4X
HMI & PC Product Compatability
Modicon
HMI & PC Connection Type
1 USB 2.0 Type A
HMI & PC Connection Type
1 USB 2.0 Type Mini B
HMI & PC Memory (RAM)
16 MB
HMI & PC Memory (Mass Storage)
64 Kb
HMI & PC Connection Type
RJ45 RS232C/RS485
HMI & PC Product Line
STU
HMI & PC Max Power Consumption
6.8 Watts
HMI & PC Screen Display Resolution
320 X 240
Manufacturer
Schneider Electric
Component
Touchscreen Panel
HMI & PC Screen Display Size
5.7"
HMI & PC Height
5.25"
HMI & PC Depth
2.25"
HMI & PC Width
6.5"
HMI & PC Interface
Touchscreen Interface
Features
The touch panel screen features 5.7inch TFT color display, supports 320 x 240 pixels QVGA resolution
It is equipped with 1 USB 2.0 type mini B, 1 USB 2.0 type A, removable screw terminal block for power supply and COM1 serial link (female RJ45, RS232C/RS485 integrated)
The screen supports Japanese (ANK, Kanji), Chinese (simplified Chinese), Taiwanese (traditional Chinese), Korean and ASCII character fonts
This touch panel screen has 65536 colors with 50,000 hours of backlight lifespan
It is an IP20/IP65 and NEMA 4X rated product
The enclosure is made of PC/PBT and PPA
Its dimensions are 163mm (width) x 56.5mm (depth) x 129.15mm (height)
It is suitable for simple machines and infrastructure applications
This product is certified by CULus, C-Tick, UL class 1 Div2 T4A or T5 and Marine
It meets IEC 61000-6-2, UL 508, UL 1604, EN 61131-2 and FCC Class A standards
Harmony STO (fromerly known as Magelis STO) is powered by the EcoStruxure operator terminal expert and STU (fromerly known as Magelis STU) is powered by Vijeo Designer.
