Code: 40806
Phoenix Contact 3004126 Fuse modular terminal block UK 5-HESILED 24
Normally In Stock
UK 5-HESILED 24 Phoenix Contact 3004126 Fuse modular Terminal Block - UK 5-HESILED 24 - Fuse Terminal Block for cartridge fuse insert, Screw Connection 1 Level 8.2 mm with 2 Connections. Not Grounded, Fused Black. 24 Volt, 6.3 Amp max rating.
Condition: New
Usually Ships Same day or Next Day$20.22
Sale Price
$16.85
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 3004126 The fuse module terminal block features a glass/ceramic fuse of type G with various configurations (5 x 20, 5 x 25, 5 x 30) and is rated for 24V nominal voltage, carrying up to 6.3A current, has one position for connection via screw, accommodates cross sections from 0.2-4mm², and is mounted using the NS35/7.5 or NS35/15 or NS32 mounting type in black color.
Specifications
Terminal Block Indication
No Indicator
Terminal Block Fused
Fused
Terminal Block Voltage Rating
24 Volt
Terminal Block Width
8.2 mm
Terminal Block Number of Levels
1
Terminal Block Number of Connections
2
Terminal Block Connection Method
Screw Connection
Terminal Block Grounded
Not Grounded
Terminal Block Max Wire Size
12
Terminal Block Min Wire Size
24
Terminal Block Component Color
Black
Terminal Block Fuse Type
G - 5 X 20 - 5 X 25 - 5 X 30
Component
Terminal Block
Manufacturer
Phoenix Contact
Terminal Block Amperage
6.3 Amp
Sub Component
Fuse Terminal Block
Sub Component
Fuse Modular Terminal Block
Model Type
UK
Features
Versions with LED
Large-surface marking
Safety lever locked in end position
Downloads
Phoenix 3004126 CAD data International.dxfPhoenix 3004126 CAD data International.pdfPhoenix 3004126 CAD data International.stpPhoenix 3004126 CAD Drawing.zipPhoenix 3004126 Manufacturers declaration English.pdfPhoenix 3004126 Safety note English.pdfPhoenix 3004126 Spec Sheet.pdfPhoenix 3004126 Tender Text English.zip
