nVent Hoffman A722525FGFS Non-Metallic Fiberglass Enclosure
Normally In Stock
Code: 4017
nVent Hoffman A722525FGFS Enclosure 72 x 25 x 24.5 inch (HxWxD) Type 4X Fiberglass Free-Stand(Floor Mount) Enclosure Hinges are corrosion-resistant fiberglass with Type 316 stainless steel hinge pins. Doors has stainless steel captivated door screws. (DOES NOT INCLUDE BACK PANEL)
Condition: New
Usually ships Same Day or Next DayDOES NOT INCLUDE BACK PANEL
$9494.06
Sale Price
$7911.72
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
nVent Hoffman A722525FGFS Enclosure 72 x 25 x 24.5 inch (HxWxD) Type 4X Fiberglass Free-Stand(Floor Mount) Enclosure Hinges are corrosion-resistant fiberglass with Type 316 stainless steel hinge pins. Doors has stainless steel captivated door screws.
Specifications
Enclosure Environment Rating
Outdoor-Indoor
Enclosure Hinge Type
Standard Hinge
Enclosure Interior Color
White
Enclosure Interior Color
Gray
Enclosure Mount Type
Free-Standing
Enclosure Composition
Fiberglass
Enclosure Latch Type
3 Point
Enclosure Depth
24.5"
Enclosure NEMA Rating
NEMA Type 4
Enclosure NEMA Rating
NEMA Type 4X
Enclosure Height
72"
Enclosure Width
25"
Enclosure Door Type
Solid
Component
Non-Metallic Enclosure
Enclosure Number of Doors
1 Door
Enclosure NEMA Rating
NEMA Type 3
Enclosure NEMA Rating
NEMA Type 3R
Enclosure NEMA Rating
NEMA Type 12
Manufacturer
Hoffman
Features
Painted steel top, bottom and side internal reinforcements standard, stainless steel corner reinforcements optional
Models have either a 3-point latching system with handle or stainless steel captivated door screws
Seamless foam-in-place gasket assures water-tight and dust-tight seal
Heavy-duty Type 316 stainless steel lifting eyes
Fiberglass material is easily punched, drilled, filed or sawed
Fiberglass-reinforced polyester material has excellent temperature and chemical resistance and exhibits outstanding physical properties
Accessory mounting channels attached horizontally to interior body sides at top, bottom and center, painted mounting channels standard, stainless steel optional
Molded-in angular sealing flange directs water away from gasket area
Large, high-impact thermoplastic data pocket (12.00 x 12.00 in. or 305 x 305 mm) is
Hinges are corrosion-resistant fiberglass with Type 316 stainless steel hinge pins
Panels and rack-mounting angles can be mounted anywhere along corner channels, panels can be mounted on sides or back
Type 316 stainless steel PowerGlide Handle on handle versions
Material is halogen free
Optional conductive panels are unpainted
Optional mild-steel panels are painted white
Downloads
Hoffman A722525FGFS User Manual.pdfHoffman A722525FGFS UL Certification.pdfHoffman A722525FGFS Spec Sheet.pdfHoffman A722525FGFS Prop 65 Notification.pdfHoffman A722525FGFS Prop 65 FAQ.pdfHoffman A722525FGFS Instruction Manual.pdfHoffman A722525FGFS EU Certification.pdfHoffman A722525FGFS Declaration of Compliance.pdfHoffman A722525FGFS CSA Certification.pdfHoffman A722525FGFS CAD Drawing.zipHoffman A722525FGFS 3D STEP CAD.zipHoffman A722525FGFS 2D DXF CAD.zip
