Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Phoenix Contact 1777992 PCB connector MSTB 2,5/ 3-STF-5,08
Normally In Stock
Code: 144547
Phoenix Contact 1777992 MSTB 2,5/ 3-STF-5,08 ,Copper Alloy,PA,I Printed-circuit board connector
Condition: New
Usually ships Same Day or Next Day $4.36
Sale Price
$3.63
MUST BUY IN PACKS OF 100
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1777992 The PCB connector has a nominal cross-sectional area of 2.5mm² and is green in color, with a rated voltage of up to 320V and a maximum current capacity of 12A. It features a socket connection type with three potentials, arranged in one row of three positions with three connections per position, and comes in the MSTB 2,5/..-STF product range. The connector has a pitch of 5.08mm and is connected via a screw mechanism with a tension sleeve, featuring an L-slotted screw head.
Specifications
Connector Amperage
12 Amp
Connector Voltage
4 Kv
Connector Material
I
Connector Material
PA
Connector Material
Copper Alloy
Manufacturer
Phoenix Contact
Connector Voltage
.21 Kv
Number of Connections
3
Number of Positions
3
Component
PCB
Sub Component
PCB Plug
Connector Voltage
320 Volt
Connector Voltage
250 Volt
Connector Voltage
630 Volt
Features
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Screwable flange for superior mechanical stability
Allows connection of two conductors
