Schneider Electric LV426967 Aluminium/Copper mechanical lug connector for 3P
Normally In Stock
Code: 92514
Schneider LV426967 Cable connector 15-125 A 3P Fixed Set of 3 Connection kit Compliant, EU RoHS Declaration China RoHS declaration, Product out of China RoHS scope. Substance declaration for your information. Molded Case Circuit Breakers PowerPact B-Frame Molded Case Circuit Brea
Condition: New
Normally Stocked*NON-CANCELLABLE, NON-RETURNABLE*
$79.08
Sale Price
$65.90
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Schneider LV426967 Cable connector 15-125 A 3P Fixed Set of 3 Connection kit Compliant, EU RoHS Declaration China RoHS declaration, Product out of China RoHS scope. Substance declaration for your information. Molded Case Circuit Breakers PowerPact B-Frame Molded Case Circuit Brea
Specifications
Manufacturer
Square D
Component
Lug Connector
Breaker Amperage Rating
15-125 Amp
Breaker Mount Type
Fixed
Breaker Number of Poles
3 Pole
Features
It is a set of 3 aluminium mechanical connectors for Compact NSXm and PowerPact B devices
These lugs are made of tin-plated aluminium an are suitable for copper and aluminium conductors
They are fastened to the terminals with lug mounting screws inserted from the bottom
The current rating is from 15A to 125A for copper wires (2.5 - 6 mm²), and the torque is 4 N.m +/- 0.4
For aluminium wires, the current rating is from 15A to 125 A (10 - 70 mm²), and the torque is 5.6 N.m +/- 0.6.
