Code: 801709
Omega HHT31R-230 Speed
Normally In Stock
Omega HHT31R-230 Speed
Condition: New
Usually ships Same Day or Next Day$1338.67
Sale Price
$1115.56
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Digital Stroboscope, Portable, 30 FPM to 14000 FPM, 0.1 FPM, ± 0.01 %, TTL Compatible, 230 Vac Powered, HHT30R Series, Each
Specifications
Manufacturer
Omega Engineering
Component
Speed
Features
NIST Calibration Certificate Included
Internal Rechargeable Batteries or AC-Powered Models
Electronic Switching Provides Continuous Cool Operation
Tachometer Mode
Accuracy± 0.01 %
Display Size12.7 mm (0.50 in)
Display Type6 Digit LCD
Handle Length108 mm
Height90.4 mm
Housing Diameter122 mm
Length229 mm
Measurement NoteFlash Energy: 180 mJ
Flash Duration: 20 to 50 µs
Flash Tube Life:100 million flashes
Trigger-to-Flash Delay: 5 µs
External Trigger Input: 1/8" phone plug, TTL compatible
Synchronization Output: 1/8" phone plug, TTL compatible
Measurement TypeFlash
Measuring Range30 to 14,000 fpm, 0.5 to 233.33 fps
Operating Temperature, Max40 °C
Operating Temperature, Min5 °C
Relative Humidity0.8
Relative Humidity NoteMax RH 80% for temperatures up to 31°C (88°F), decreasing linearly to 50% RH @ 40°C (104°F)
Resolution0.1 fpm
Tachometer Accuracy±0.01% rdg or ±0.2 rpm
Tachometer Range5 to 200000 rpm
Tachometer Resolution0.1 rpm, up to 99,999.9 rpm
1 rpm, 100,000 to 200,000 rpm
Tripod Mount1/4-20 UNC
Width93 mm
