Phoenix Contact 2905989 Type 1 surge protection plug FLT-SEC-P-T1-440/35-P
Normally In Stock
Code: 71962
FLT-SEC-P-T1-440/35-P Phoenix 2905989 Replacement plug 400 VAC pluggable Type 1 surge protection plug Surge Protection
Condition: New
Usually ships Same Day or Next Day$573.85
Sale Price
$478.21
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2905989 The FLASHTRAB SEC PLUS 440 product range offers a replacement plug that is designed to be free from leakage current for lightning arresters, suitable for both L-N (Line-to-Network) and L-PE (Line-to-Personnel Earth) paths.
Specifications
Fault Warning
Optical
Arrester Class according to IEC
II
Arrester Class according to IEC
T2
Manufacturer
Phoenix Contact
Connection Method
Screw Connection
Surge Protector Type
Replacement Plug
Maximum Continous Voltage
335 Volt
Nominal Discharge Current
20 Ka
Surge Protector Line Voltage
400 Volt
Component
Surge Protection Plug
Features
Optimum protective effect in the event of high-energy lightning currents, thanks to spark gap technology with low residual voltage characteristic
Easy to maintain due to consistently pluggable protection modules
Excellent level of information provided by mechanical/visual status indicator and remote indication contact
Surge protection family for universal use with optimum energy coordination from the lightning current arrester to the device protection
Maximum performance in a minimum amount of space: compact design with high discharge capacity at high nominal voltage
