Phoenix Contact 2905473 Type 1 surge protection plug FLT-SEC-P-T1-N/PE-350/100-P
Normally In Stock
Code: 71958
FLT-SEC-P-T1-N/PE-350/100-P Phoenix 2905473 Replacement plug 240 VAC pluggable Type 1 surge protection plug Surge Protection
Condition: New
Usually ships Same Day or Next Day$327.91
Sale Price
$273.26
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2905473 A replacement plug that is designed to be free from leakage current for use in lightning arresters as part of the FLASHTRAB SEC product range and intended for the N-PE path.
Specifications
Fault Warning
Optical
Fault Warning
Remote Indicator Contact
Arrester Class according to IEC
C1
Arrester Class according to IEC
C2
Arrester Class according to IEC
C3
Arrester Class according to IEC
D1
Direction of Action
Line-Line
Direction of Action
Line-Signal Ground-Shield
Direction of Action
Optional Signal Ground-Shield-Earth Ground
Manufacturer
Phoenix Contact
Connection Method
Screw Connection
Surge Protector Type
Surge Protection For Measurement And Control Technology
Maximum Continous Voltage
6 Volt
Nominal Discharge Current
10 Ka
Surge Protector Line Voltage
240 Volt
Component
Surge Protection Plug
Features
Optimum protective effect in the event of high-energy lightning currents, thanks to spark gap technology with low residual voltage characteristic
Easy to maintain due to consistently pluggable protection modules
Excellent level of information provided by mechanical/visual status indicator and remote indication contact
Surge protection family for universal use with optimum energy coordination from the lightning current arrester to the device protection
Low voltage protection level for direct protection of end devices in the main distribution area
Downloads
Phoenix 2905473 CAD data International.dxfPhoenix 2905473 CAD data International.pdfPhoenix 2905473 CAD data International.stpPhoenix 2905473 Flyer English-2.pdfPhoenix 2905473 Flyer English.pdfPhoenix 2905473 Manufacturers declaration English.pdfPhoenix 2905473 Manufacturers declaration International.pdfPhoenix 2905473 Package Slip International.pdfPhoenix 2905473 Surge Protection English.pdfPhoenix 2905473 Tender Text English.zip
