Phoenix Contact 2905347 Type 2 surge protection plug VAL-SEC-T2-N/PE-350-P
Normally In Stock
Code: 71950
VAL-SEC-T2-N/PE-350-P Phoenix 2905347 Replacement plug 240 VAC pluggable Type 2 surge protection plug Surge Protection
Condition: New
Usually ships Same Day or Next Day$132.30
Sale Price
$110.25
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2905347 A replacement plug for surge arresters in the VALVETRAB SEC product range is available for use on the N-PE path.
Specifications
Fault Warning
Optical
Arrester Class according to IEC
II
Arrester Class according to IEC
T2
Max Discharge Capacity
100 A (260 V)
Manufacturer
Phoenix Contact
Connection Method
Screw Connection
Surge Protector Type
Replacement Plug
Maximum Continous Voltage
264 Volt
Nominal Discharge Current
50 Ka
Surge Protector Line Voltage
240 Volt
Component
Surge Protection Plug
Features
More space in the control cabinet due to the narrow overall width of just 12 mm per position and use without separate backup fuse up to 315 A gG
Easy to maintain due to consistently pluggable protection modules
Excellent level of information provided by mechanical/visual status indicator and remote indication contact
Surge protection family for universal use with optimum energy coordination from the lightning current arrester to the device protection
Downloads
Phoenix 2905347 CAD data International.dxfPhoenix 2905347 CAD data International.pdfPhoenix 2905347 CAD data International.stpPhoenix 2905347 Flyer English-2.pdfPhoenix 2905347 Flyer English.pdfPhoenix 2905347 Manufacturers declaration English.pdfPhoenix 2905347 Manufacturers declaration International.pdfPhoenix 2905347 Package Slip International.pdfPhoenix 2905347 Surge Protection English.pdfPhoenix 2905347 Tender Text English.zip
