Phoenix Contact 2905356 Type 2 surge protection plug VAL-SEC-T2-N/PE-175-P
Normally In Stock
Code: 71944
VAL-SEC-T2-N/PE-175-P Phoenix 2905356 Replacement plug 120 VAC pluggable Type 2 surge protection plug Surge Protection
Condition: New
Usually ships Same Day or Next Day$132.30
Sale Price
$110.25
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2905356 A replacement plug suitable for use with surge arresters from the VALVETRAB SEC product range is designed for the low-earth (N-PE) path.
Specifications
Fault Warning
Optical
Fault Warning
Remote Indicator Contact
Arrester Class according to IEC
II
Arrester Class according to IEC
T2
Manufacturer
Phoenix Contact
Connection Method
Screw Connection
Surge Protector Line Voltage
120 Volt
Surge Protector Type
Surge Arrester
Maximum Continous Voltage
580 Volt
Nominal Discharge Current
15 Ka
Component
Surge Protection Plug
Features
More space in the control cabinet due to the narrow overall width of just 12 mm per position and use without separate backup fuse up to 315 A gG
Easy to maintain due to consistently pluggable protection modules
Excellent level of information provided by mechanical/visual status indicator and remote indication contact
Surge protection family for universal use with optimum energy coordination from the lightning current arrester to the device protection
Downloads
Phoenix 2905356 CAD data International.dxfPhoenix 2905356 CAD data International.pdfPhoenix 2905356 CAD data International.stpPhoenix 2905356 Flyer English-2.pdfPhoenix 2905356 Flyer English.pdfPhoenix 2905356 Manufacturers declaration International.pdfPhoenix 2905356 Package Slip International.pdfPhoenix 2905356 Surge Protection English.pdfPhoenix 2905356 Tender Text English.zip
