Littelfuse TSB2190 Delay On Break Timer
Normally In Stock
Code: 566531
Littelfuse TSB2190 - Delay on Break Series - 24 Volt - Surface mount with 1 #10 (M5 x 0.8) screw - 1 A steady state; 10 A inrush @ 60°C (MUST BUY IN PACKS OF 10)
Condition: New
Usually ships Same Day or Next Day$86.00
Sale Price
$71.67
MUST BUY IN PACKS OF 10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Littelfuse TSB2190 is an encapsulated circuitry with a 0.25 in. (6.35 mm) male quick connect terminals termination type. It has a 1 A steady state and 10 A inrush @ 60°C output load rating. With an input tolerance of ±20%, it operates at 50/60 Hz AC line frequency. Featuring a ≤±10% setpoint vs ambient temperature and operating voltage, it ensures accurate repeat accuracy of ±2% or 20 ms. Other highlights include a power consumption of ≤2 VA, a time delay tolerance of ±5%, and a reset time of ≤150 ms. Its insulation resistance is ≥100, and it has a dielectric breakdown of ≥2000V terminals to mounting surface. The output voltage drop is ≅2.5 V @ 1 A, and the open state leakage current is ≅5 A @ 230V AC.
Specifications
Manufacturer
Littelfuse
Component
Time Delay Relay
Coil Voltage Rating
24 Volt
Relay Mounting
Surface Mount
Sub Component
Delay On Break
Relay Timing Range
90 S
Features
Analog circuitry
Totally solid state and encapsulated
Wide time delay range
1A steady, 10A inrush solid state output
