Littelfuse TDUS3000A Time Delay Relay - 24-120 Volt, Normally Open
Normally In Stock
Code: 566444
Littelfuse TDUS3000A - Dedicated Single-Shot Delay-On-Make Timer Series - 24-120 Volt - Surface mount with 1 #10 (M5 x 0.8) screw - 1 A steady state; 10 A inrush @ 60°C (MUST BUY IN PACKS OF 10)
Condition: New
Usually ships Same Day or Next Day$122.26
Sale Price
$101.88
MUST BUY IN PACKS OF 10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Littelfuse TDUS3000A is an encapsulated solid-state relay with a 1A steady state output load rating and 10A inrush capability at 60°C. It features 0.25 inch (6.35 mm) male quick connect terminals for easy installation. With an input AC line frequency of 50/60 Hz and ±20% input tolerance, it offers reliable performance. The relay has a humidity resistance of 95% relative non-condensing. With a repeat accuracy of ±0.5% or 20 ms, it ensures precise control. It has a power consumption of ≤2 VA and a reset time of ≤150 ms. The relay provides insulation resistance of ≥100 and a dielectric breakdown of ≥2000V between terminals and mounting surface. With a setting accuracy of ≤±2% or 20 ms, it guarantees accurate timing. The relay has an initiate time of ≤20 ms and an open state leakage current of ≅5 A at 230 V ac.
Specifications
Manufacturer
Littelfuse
Component
Time Delay Relay
Relay Mounting
Surface Mount
Relay Throws
Normally Open
Sub Component
Single Shot
Relay Timing Range
1 - 1023 S
Coil Voltage Rating
24-120 Volt
