Littelfuse T10120 Time Delay Relay - 115 Volt, Double Throw, Single Pole
Normally In Stock
Code: 566366
Littelfuse T10120 - Solid-State On-Delay Timer Series - 115 Volt - #8 screws - Pilot Duty: 480 VA @ 240 V ac (MUST BUY IN PACKS OF 10)
Condition: New
Usually ships Same Day or Next Day$256.01
Sale Price
$213.34
MUST BUY IN PACKS OF 10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Littelfuse T10120 is a pilot duty relay with a load rating of 480 VA at 240 V ac. It has a termination type of 7 in.-lbs. and is suitable for use with 12-18AWG wire. With an input AC line frequency of 50/60 Hz, the relay provides a repeat accuracy of ±1%. It can handle a maximum input power of 5.
Specifications
Relay Throws
Double Throw
Relay Poles
Single Pole
Manufacturer
Littelfuse
Component
Time Delay Relay
Coil Voltage Rating
115 Volt
Relay Mounting
Screw
Sub Component
Delay On Make
Relay Timing Range
6 S
