Littelfuse ESDR320A0P Solid State Timer (Recycling)
Normally In Stock
Code: 566152
Littelfuse ESDR320A0P - Recycling Timer Series - 24 Volt (DC) - Surface mount with 1 #10 (M5 x 0.8) screw - 1 A steady state; 10 A inrush @ 45°C (MUST BUY IN PACKS OF 10)
Condition: New
Usually ships Same Day or Next Day$120.42
Sale Price
$100.35
MUST BUY IN PACKS OF 10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Littelfuse ESDR320A0P is a compact and reliable solid-state relay designed for various applications. It features a 1A steady state output load rating, with a 10A inrush rating at 45°C. With 0.25-inch male quick connect terminals, it ensures easy and secure connection. It has a wide input tolerance of ±20% and a repeat accuracy of ±0.1% or 20ms. The relay is encapsulated for added protection and has a power consumption of ≤1W. The setpoint vs ambient temperature and operating voltage is precise at ≤±2%. It has a quick reset time of ≤150ms and a time delay tolerance of ≤±5%. The relay guarantees high insulation resistance of ≥100MΩ and dielectric breakdown of ≥2000V between terminals and mounting surface. With a low output voltage drop of 1V @ 1A, it efficiently regulates power flow. This relay offers long electrical life of 1x10⁶ and mechanical life of 1x10⁷, ensuring durability. DC units are protected against reverse polarity. The input DC ripple is ≤10%.
Specifications
Relay Timing Range
0.1 - 10 S
Manufacturer
Littelfuse
Component
Time Delay Relay
Relay Mounting
Surface Mount
Coil Voltage Rating
24 Volt (DC)
Sub Component
Recycle
Features
Microcontroller based
1A steady, 10A inrush solid-state output
Totally solid state and encapsulated
ON/OFF recycling with independent adjustment of both time periods
Compact, low cost design measuring 2 in. (50.8mm) square
