Code: 566050
Littelfuse FB230A Flasher Failure Alarm Relay
Normally In Stock
Littelfuse FB230A - Flasher and Incandescent Beacon Alarm Relay Series - 230 Volt - Surface mount with two #6 (M3.5 x 0.6) screws
Condition: New
Usually ships Same Day or Next Day$490.73
Sale Price
$408.94
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Littelfuse FB230A is an encapsulated product with a 7 position barrier block termination. It features one isolated SPDT relay rated at 5A resistive, and two solid-state line voltage outputs with ratings of 0.5A steady and 5A inrush. Its input AC line frequency ranges from 50 to 60 Hz, with a tolerance of ±15%. The trip delay range for flasher failure is fixed at 6 seconds (-0/+40), while for lamp failure it is fixed at 10 seconds (-0/+40). It is equipped with LED indicators for lamp failure and flasher failure.
Specifications
Manufacturer
Littelfuse
Coil Voltage Rating
230 Volt
Relay Mounting
Surface Mount
Component
Lighting Control
Features
Provides repeatable timing logic for machine control, sequencing, lockout, anti-short-cycle, or delay functions without custom controls.
