nVent Hoffman E6PBGXM Steel 22.5mm Deep Push Button Enclosure
Normally In Stock
Code: 5222
nVent Hoffman E6PBGXM 8.5" x 5" x 4" Type 12,Type 13 Indoor 6 Hole 22.5-mm Deep Push Button Steel Enclosure (DOES NOT INCLUDE BACK PANEL)
Condition: New
Usually ships Same Day or Next DayDOES NOT INCLUDE BACK PANEL
$299.65
Sale Price
$249.71
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
nVent Hoffman E6PBGXM Steel 22.5mm Deep Push Button Enclosure 22.5-mm Deep Steel Pushbutton Enclosure Type 12,13 indoor use for pushbuttons and switches, with added depth to accommodate additional pushbutton contact blocks.
Specifications
Enclosure Depth
4"
Enclosure Hinge Type
Standard Hinge
Enclosure Interior Color
Gray
Enclosure Composition
Painted Steel
Enclosure Door Type
Pushbutton
Enclosure Height
8.5"
Enclosure Width
5"
Component
Push Button Enclosure
Enclosure Environment Rating
Indoor
Enclosure Latch Type
Screw
Push Button Number
6
Enclosure Number of Doors
1 Door
Enclosure NEMA Rating
NEMA Type 12
Enclosure NEMA Rating
NEMA Type 13
Manufacturer
Hoffman
Features
Oil-resistant gasket
Bonding provision on cover
Grounding nut in body of enclosure
Enclosures with more than one column of pushbutton holes have internal detachable hinge to hold cover open during installation
Captivated cover screws thread into sealed wells
Seams continuously welded and ground smooth
External welded-on mounting brackets for easy installation
22.5-mm size holes
Factory stamped 4-way pushbutton holes
