Application: Designed to house electrical controls, instruments and components used in an indoor or outdoor environment to provide a degree of protection for the equipment inside the enclosure against ingress of solid foreign objects (falling dirt)

and provide a degree of protection with respect to the harmful effects on the equipment due to the ingress of water (rain, sleet, snow). For outdoor application a drip shield and drain vent is recommended.For details about the design, performance expectations, applications and design suggestions - See Design Considerations www.saginawcontrol.com/instman/considerations.pdf

0.075 In. carbon steel

Seams continuously welded and ground smooth

Flange trough collar around all sides of door opening

Collar studs 3/8-16 provided for mounting optional panels

Mounting holes in back of the enclosure for wall mounting

Mounting hardware, sealing washers and hole plugs included

Black keylocking padlocking handles

3-point latching mechanism

Overlapping Doors

Removable print pocket

Pour in place oil & water resistant gasket

Ground stud on door and body.
