Phoenix Contact 2982760 Solid-state relay module PLC-OSC- 24DC/230AC/ 2/ACT
Normally In Stock
Code: 24533
Phoenix Contact 2982760 Miniature Solid State Relay PLC-OSC- 24DC/230AC/ 2/ACT online from authorized Phoenix Contact Replay distributor RSP Supply. Check stock and pricing, view product specifications, and order online.
Condition: New
Usually ships Same Day or Next Day $50.04
Sale Price
$41.70
MUST BUY IN PACKS OF 10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2982760 The output interface for a PLC system features a basic terminal block with screw connection and plug-in miniature solid-state relay. This component is designed to be mounted on DIN rail NS 35/7,5, accommodating up to 1 N/O contact. The input voltage requirements are 24 V DC, while the output range spans from 24 - 253 V AC at a maximum current of 2 A.
Specifications
Relay Mounting
Din Rail
Relay Indication
LED Indicator
Relay Connection Type
Screw Connection
Component
Relay Module-Solid State
Manufacturer
Phoenix Contact
Relay Input Amperage
9 Mamp
Coil Voltage Rating
12-24 Volt
Relay Application
Input Function Output Function
Relay Load Voltage AC Rating
230 Volt
Features
PLC actuator series with solid-state power relays for coupling the controller and actuators, such as motors, contactors, valves, etc.
Downloads
Phoenix 2982760 Application Note English.pdfPhoenix 2982760 CAD data International.dxfPhoenix 2982760 CAD data International.pdfPhoenix 2982760 CAD data International.stpPhoenix 2982760 CAD Drawing.zipPhoenix 2982760 Circuit Diagram.jpgPhoenix 2982760 Manufacturers declaration English.pdfPhoenix 2982760 Manufacturers declaration International.pdfPhoenix 2982760 Product Information English.pdfPhoenix 2982760 Spec Sheet.pdfPhoenix 2982760 Tender Text English.zipPhoenix 2982760 Various International.pdf
