Phoenix Contact 0903028 Electronic circuit breaker EC-E1 6A
Normally In Stock
Code: 23425
Phoenix Contact 0903028 Supplementary Electronic Circuit Breaker 6 Amp, UL 2367 Recognized Din Rail Mount for up to 32 VDC 1-position, tripping Overcurrent protection (1.3-1.8 times Amp rating). Single Pole with ST one NO auxilary contact, complete unit.
Condition: New
Usually ships within 7-14 days. Call for ship time$123.26
Sale Price
$102.72
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 0903028 Electronic circuit breaker, signal contact: 1 N/O contact, nominal current: 6 A
Specifications
Breaker Type
Supplementary Breaker
Breaker Mount Type
Din Rail
Breaker Amperage Rating
6 Amp
Breaker Auxilary Contacts
Single Throw NO
Breaker Switching Type
Electronic
Breaker Mechanism Type
Electronic
Breaker UL Rating
UL 2367 Recognized
Breaker Number of Poles
Single Pole
Breaker Protection For
Sensitive Equipment
Breaker Trip Speed
Extra Fast Trip
Breaker Overcurrent Protection Rating
A Curve Under 2 X Amp Rating
Breaker Unit
Complete Unit
Breaker Voltage Rating
24 VDC
Breaker Contact Type
N-O
Breaker Function
N-O Contact
Manufacturer
Phoenix Contact
Component
Electronic Circuit Breaker
Features
Error-free short-circuit detection even across long cable paths with the electronics characteristic curve
Active current limitation to improve the capacity of the upstream power supply
Increased system transparency with integrated floating remote indication contact (N/O)
Downloads
Phoenix 0903028 CAD data International.dxfPhoenix 0903028 CAD data International.pdfPhoenix 0903028 CAD data International.stpPhoenix 0903028 CAD Drawing.zipPhoenix 0903028 Data Sheet English.pdfPhoenix 0903028 Flyer English.pdfPhoenix 0903028 Manufacturers declaration English.pdfPhoenix 0903028 Manufacturers declaration International.pdfPhoenix 0903028 Spec Sheet.pdfPhoenix 0903028 Tender Text English.zipPhoenix 0903028 User Manual.pdfPhoenix 0903028 Various English.pdf
