Phoenix Contact 1788444 PCB header MVSTBU 2,5/12-GFB-5,08
Normally In Stock
Code: 154481
Phoenix Contact 1788444 MVSTBU 2,5/12-GFB-5,08 ,I,PA Printed-circuit board connector
Condition: New
Usually ships Same Day or Next Day $30.71
Sale Price
$25.59
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1788444 The direct plug-in block has a nominal cross-sectional area of 2.5 mm² and is coloured green, carrying a nominal current of 12 A at a rated voltage of 320 V for three-phase applications. It features a Sn contact surface with a pin connection type and has 12 potentials arranged in a single row, with each potential having 12 connections and a pitch of 5.08 mm. The plug-in system is the COMBICON MSTB 2,5, and it uses screw connections with tension sleeves, featuring an L slotted screw head and direct mounting capabilities.
Specifications
Connector Amperage
12 Amp
Connector Voltage
4 Kv
Connector Material
I
Connector Material
PA
Component
Direct Plug-In Block
Manufacturer
Phoenix Contact
Number of Positions
12
Connector Voltage
320 Volt
Connector Voltage
630 Volt
Features
Direct plug-in blocks with mounting flanges for screw connection on mounting panels or unit housing
Can be combined with the MSTB 2,5 range
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
Well-known connection principle allows worldwide use
Allows connection of two conductors
